Luftförsvarsgruppcentral
The complete photographic sequence is presented in its original article context, alongside the facility dossiers drawn from the same source.
Militärt · 31 August 2015 · 12 photographs
Reviewed 15 August 2026 · geometry completeness 52/100 · Low
The current dossier handles identity well and uses the focal 200 m² / 2,153 ft² rather than multiplying 64 sites. However, the SEK 41.25m base still derives concrete as 2 m³ per m² and omits explicit excavation, backfill, waterproofing and drainage. A half protection package is not a supplier-buildable scope.
The article distinguishes the national LGC class from one preserved focal facility. It supports 64 LGCs in STRIL 50, a 150 m² / 1,615 ft² type design, and one preserved buried concrete bunker of just over 200 m² / 2,153 ft² for ten operators plus a commander, with automatic diesel backup and protection against smaller bombs and gas. It does not give shell thickness, excavation, entry/escape geometry, or cost.
published: focal facility just over 200 m² / 2,153 ft²; buried concrete bunker a few metres below grade; ten staff plus commander; 150 m² / 1,615 ft² standard type as class context; 64 LGCs nationally as programme context | not_published: shell/slab thickness; plan dimensions and floors; excavation/backfill; entry and escape; reinforcement and waterproofing
operations room and map/display equipment; telephone reporting system; small automatically starting diesel generator; gas protection
buried shell and reinforcement; excavation/backfill and waterproofing; protected ventilation; generator; communications and operations fit-out
One preserved approximately 200 m² / 2,153 ft² unit; 64 national LGCs are context only.
Retain one-facility scope; derive shell from measured footprint and thickness; add earthworks/waterproofing/drainage; split generator, protected ventilation, doors/penetrations and communications; show the 64-site count only in contextual facts
as-built plan and section; shell and reinforcement schedule; entry/escape geometry; generator capacity; protected-ventilation schedule; historic final cost
Facility Quantity Based label overstates geometry quality; earthworks omitted; protection scope is a fractional lump sum
1 dossier connect the article to distinct facilities or facility groups.
12 photographs sourced from the original article, with captions where available.
